Connectivity System Setup with the Targeted Reference Design
Installing the Device Drivers
This sections describes the steps to install the device drivers for the Kintex-7 Connectivity
TRD after completion of the above hardware setup steps.
1.
2.
If Fedora 16 is installed on the PC system's hard disk, boot as a root-privileged user,
proceed to step 3. Otherwise continue with step 2.
To boot from the Fedora 16 Live DVD provided in the kit, place the DVD in the PC's
CD-ROM drive. The Fedora 16 Live Media is for Intel-compatible PCs. The DVD
contains a complete, bootable 32-bit Fedora 16 environment with the proper packages
installed for the TRD demonstration environment. The PC boots from the CD-ROM
drive and logs into a liveuser account. This account has kernel development root
privileges required to install and remove device driver modules.
Note: Users might have to adjust BIOS boot order settings to enure that the CD-ROM drive is
the first drive in the boot order. To enter the BIOS menu to set the boot order, press the DEL or
F2 key when the system is powered on. Set the boot order and save the changes. (The DEL or
F2 key is used by most PC systems to enter the BIOS setup. Some PCs might have a different
way to enter the BIOS setup.)
The PC should boot from the CD-ROM drive. The images in Figure 12 are seen on the
monitor during boot up.
X-Ref Target - Figure 12
Fir s t S creen
Kintex-7 FPGA Connectivity Kit
Figure 12:
L as t Boot S creen
Fedora 16 LiveCD Boot Sequence
www.xilinx.com
Booted
UG929_65_061212
19
UG929 (v1.0 Draft) June 21, 2012
